Calibration adjustments to the bed are not to be performed by members. If calibration is needed, make a request in the #woodshop SLACK channel.
Manual
Forstner Bit RPM Guide
Features:
- 6” of quill travel with one revolution of the handle
- Digital RPM readout allows user to optimize the spindle speed to the application
- Fence system adjustable for a perfect 90-degree relationship to the table and for rapid alignment of stock
- Includes 5/8" keyed chuck
- Laser guides provide an accurate indication for tool point
- Mechanical variable speed allows for full range of speeds with no belt changes
- Oversize cast iron base for added stability
- Reversible handles can be mounted on either side of the machine for more comfortable working of the quill
- Two independently adjustable LED work lights eliminates shadows
- Work table can be rotated to a full 90 degree position
Specifications:
- Base Dimensions (In.) 13-1/2 x 20-1/2
- Base Work Table (In.) 10 x 12
- Chuck Size (In.) 5/8
- Column Diameter (In.) 3-1/8
- Model Number PM2800B
- Motor Amps 20/15
- Motor (HP) 1 HP, 115/230V, 1Ph
- Motor Phase 1
- Motor Power (HP) 1
- Motor Voltage (V.) 115/230
- Overall Dimensions (L x W x H) (In.) 18 x 20.25 x 71
- Prewired Voltage (V.) 115
- Prop 65 Cancer and Reproductive Harm
- Quill Diameter (In.) 2.6
- Spindle Distance to Base (In.) 44-3/4
- Spindle Travel (In.) 6
- Style (Type) Floor
- Swing (In.) 18"
- Gross Weight 266.0
- Net weight 246.0
